5 Car Garage with 500 Square Feet of Shop Provides an ideal storage and work environment for your cars. These are building plans. The building is 30x50 feet.
There are five standard-sized 10'x20' parking spaces, behind the parking is a 10'x50' shop area.
The ceiling height is 12'-0", so you can fit an 11'-0" high door if desired, however 10'-0" doors are specified in the plans.
There is a man door at the side, and one 3040 window for each bay, along the back wall.
The wall height is below what would typically require engineering. We can refer engineering , if required, or make modifications.
We can provide a plan to turn one of the bays into a micro-apartment, or office , if desired.
Plan package: floor plans, four elevations, a section, roof framing plan, foundation plan, connection details, notes, general specifications,
The walls are 2"x6" framing, the roof is pre-engineered trusses, the floor is concrete slab.
Questions? To get answers. please use any contact form at:
The purchase entitles the buyer to use the plans for one project only. The plans are copyrighted and may not be resold, posted on the internet or used for multiple projects. Five prints are allowed for buyer's use under this license.
Building plans for a 30x50 foot 5 Car Garage With 500 Square Foot Shop Area.
